Maximum repetitive peak reverse voltage: 400V
Maximum RMS voltage: 280V
Maximum DC blocking voltage: 400V
Maximum average forward rectified current at TL = 110 °C: 1A
Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load: 30A
Operating and storage temperature range: -55 TO 105 °C
Maximum instantaneous forward voltage: 1V
Maximum DC reverse current at rated DC blocking voltage: 10μA
Maximum reverse recovery time: 50ns
Typical junction capacitance: 15pF
