Features

• Low forward voltage drop
• High current capability
• High reliability
• High surge current capability
• Epitaxial construction

Ratings

Maximum repetitive peak reverse voltage: 40V
Maximum RMS voltage: 28V
Maximum DC blocking voltage: 40V
Maximum average forward rectified current: 3A
Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load: 120A
Operating temperature range: -65 TO 125 °C
Maximum instantaneous forward voltage @ 3A: 0.55V
Maximum DC reverse current at rated DC blocking voltage: 0.2mA
Typical junction capacitance: 320pF
