Features

• Channel Polarity: P-Channel
• Max. Continuous Drain Current, VGS @ -10V: -12A
• Max. Pulsed Drain Current: -48A
• Max. Power Dissipation: 45W
• Max. Static Drain-to-Source On-Resistance: 175mΩ
• Min. Drain-to-Source Breakdown Voltage: -55V
• Gate Threshold Voltage: (Min)-2V, (Max)-4V
• Turn-On Delay Time: 13ns
• Rise Time: 55ns
• Turn-Off Delay Time: 23ns
• Fall Time: 37ns
• Package: TO-220AB
