Features

Maximum repetitive peak reverse voltage: 1000V
Maximum RMS bridge input voltage: 700V
Maximum average forward rectified output current at TA=25°C: 2A
Peak forward surge current single sine-wave superimposed on rated load: 60A
Maximum instantaneous forward voltage drop per leg at 2.0A: 1.1V
Operating junction and storage temperature range: -55 to 150°C
